2011 Wangler Sport front end wobble

BLACKJKU

JK Enthusiast
Lifetime Supporting Member
Joined
Feb 22, 2020
Messages
421
Location
Huntington In
Have you jacked up your front axle and had someone move a tire back and forth so you can see if anything doesn't look right?


BLACKJKU

JK Enthusiast
Lifetime Supporting Member
Joined
Feb 22, 2020
Messages
421
Location
Huntington In
It also will help to hold one wheel while someone is moving the other one while looking. Steering gearboxes can get some free play after some age, you can tighten up the screw on top of the gearbox to tighten it back up if that's the problem.


Chris

Administrator
Staff Member
Joined
Sep 28, 2015
Messages
31,028
Location
Florence, AZ
Yep, that's exactly what I would do too. It's called a "dry steering test".

Joined
Apr 27, 2020
Messages
41
Location
North Eastern, Maryland
Shimmy check list:
  1. Check and balance the wheels/tires
  2. Check for play in the pitman arm
  3. Check for play in the ball joints
  4. Check or replace the steering damper
  5. Check the drag link, Tie rod ball joints for signs of wear.
  6. Re-seat the wheels/tires on the rotors.
  7. Check the upper & lower control arm bushings

  • Like
Reactions: Chris
OP
S

STAnavy2000

New Member
Joined
Mar 30, 2020
Messages
8
Location
Jacksonville, FL
Tanks all for the help. I was crunched for tim, patience and just really wanted it to work right. I took it to a local expert who I would recommend in the Jacksonville area. Overbuilt Customs. I was extremely happy with their work and the owner and staff are absolute professionals. The operation is top shelf.
Thanks for all the guidance from the JK Forum folks.


Chris

Administrator
Staff Member
Joined
Sep 28, 2015
Messages
31,028
Location
Florence, AZ
Tanks all for the help. I was crunched for tim, patience and just really wanted it to work right. I took it to a local expert who I would recommend in the Jacksonville area. Overbuilt Customs. I was extremely happy with their work and the owner and staff are absolute professionals. The operation is top shelf.
Thanks for all the guidance from the JK Forum folks.
What ended up being the issue?
